CGW™ thermal conductive grease is a two-component thermal conductive grease designed to improve heat dissipation and reduce contact thermal resistance. The paste-like material conforms to uneven surfaces and cures at room temperature, providing reliable thermal interface performance for demanding electronic and industrial applications.
Key Features
Two-Liquid Formulation
Two-liquid thermal conductive grease designed for reliable heat dissipation and gap filling.
Room-Temperature Curing
Cures at room temperature, with no reaction by-products during curing.
Conforms to Uneven Surfaces
Paste-like material follows uneven surfaces and helps reduce contact thermal resistance.
Flexible After Curing
Flexible and adhesive after curing, helping relieve stress caused by thermal expansion differences.
Multiple Thermal Conductivity Grades
Available in multiple grades from 2 to 6 W/m-K to meet different thermal management requirements.
Low Molecular Cyclic Siloxane
Low molecular cyclic siloxane is carefully controlled to support demanding electronic applications.
CGW™ Series Grades & Technical Data
The CGW™ Series is available in multiple grades with different thermal conductivity, hardness and specific gravity characteristics to meet different thermal management requirements. For detailed technical information, please refer to the official Sekisui Polymatech website.
| Grade | Thermal Conductivity* | Hardness Type E | Shore 00 | Specific Gravity | Operating Temp. |
|---|---|---|---|---|---|
| CGW-2 | 2 W/m-K | 25 | 50 | 2.0 | -40 to 150°C |
| CGW-3 | 3 W/m-K | 30 | 55 | 2.8 | -40 to 150°C |
| CGW-3LW | 3 W/m-K | 30 | 55 | 2.2 | -40 to 150°C |
| CGW-3.6 | 3.6 W/m-K | 20 | 40 | 2.9 | -40 to 150°C |
| CGW-4 | 4 W/m-K | 25 | 50 | 3.0 | -40 to 150°C |
| CGW-4.5 | 4.5 W/m-K | 30 | 55 | 3.2 | -40 to 150°C |
| CGW-6 | 6 W/m-K | 25 | 50 | 3.4 | -40 to 150°C |
Thermal conductivity values shown are based on ASTM D5470, first method. Please contact us for detailed technical data and the latest datasheet.
Applications
CGW™ Thermal Conductive Grease is designed for thermal management applications where reliable heat dissipation, surface conformity and stress relief are important.
Electronics & Semiconductor
Thermal interface applications for electronic and semiconductor devices requiring efficient heat dissipation.
Automotive & Mobility
Thermal management solutions for components used in automotive and mobility applications.
Power Electronics
Thermal interface material for heat-generating components and power electronic devices.
Industrial Equipment
Thermal management for industrial equipment and applications with demanding thermal requirements.
Why Choose CGW™?
Surface Conformity
Paste-like material conforms to uneven surfaces, helping improve contact between thermal interfaces.
Stress Relief
Flexible and adhesive after curing, helping relieve stress caused by differences in thermal expansion.
Grade Selection
Multiple grades provide different thermal conductivity, hardness and specific gravity characteristics for different requirements.
How CGW™ Thermal Conductive Grease Works
CGW™ Thermal Conductive Grease is designed to improve thermal contact between heat-generating components and heat-dissipating surfaces. Its paste-like formulation can conform to uneven or irregular surfaces, helping reduce contact thermal resistance at the interface.
The two-liquid formulation cures at room temperature after application and becomes flexible and adhesive. This flexibility helps accommodate differences in thermal expansion between adjoining materials during operation, supporting reliable thermal interface performance.
The CGW™ Series is available in multiple thermal conductivity grades, allowing material selection according to the thermal requirements of different applications. Depending on the grade, thermal conductivity ranges from 2 to 6 W/m-K based on ASTM D5470, first method.
For applications where thermal performance, surface conformity and long-term interface reliability are important, CGW™ provides a flexible material option for electronics, semiconductor, automotive, power electronics and industrial equipment.
CGW™ thermal conductive grease can be selected according to the thermal and mechanical requirements of each application. Different grades provide different levels of thermal conductivity, hardness and specific gravity, allowing engineers to select a suitable material for their thermal interface design. This flexibility makes the CGW™ Series suitable for a wide range of electronic and industrial applications.
